ITM Lifting Shoulder Eyebolt Din 580 - 10mm. 0.23T
Product Code: TM9240-02100
Next shipment: 13-Aug-2026
$3.47 (Incl. GST)
TM9240-02100 | ITM Lifting Shoulder Eyebolt Din 580 - 10mm. 0.23T
Features
• Galvanised finish
• Specifications, batch and brand markings as per Australian Standards requirements
• Tested and certified to AS 2317
Specifications
• Thread: M10
• W.L.L (t): 0.23
• Dimension D (mm): 10
• Dimension D1 (mm): 25
• Dimension D2 (mm): 25
• Dimension D3 (mm): 10
• Dimension H (mm): 45
• Dimension H1 (mm): 17
• Dimension W (mm): 45
